Item No.: 920013_variante

Thermoelectric coolers ST 3075

from 608,00  excl. VAT
from 723,52  incl. VAT

Delivery time: 1-3 Working days


Product description

The industrial Peltier cooling units in the ST series rely on the proven Peltier effect to provide efficient cooling without conventional refrigerants. This makes them not only particularly environmentally friendly, but also virtually maintenance-free in operation.

Their flexible mounting options allow the units to be used in any position, whether semi-recessed or surface-mounted. This means they can be optimally adapted to different housing types and cabinet sizes.

With a wide power range from 30W to 800W, the ST series covers a wide range of applications. This allows them to be optimally adapted to differnt housing types and cabinet sizes. They also provide reliable cooling at ambient temperatures form -20°C to +70°C and in dusty or oily environments. The IP66 protection rating also makes them suitable for outdoor use.

Features:

-> Low-maintenance cooling without refrigerant
-> Flexible installation as a semi-mounted or Wall-mounted in any position
-> Robust design for dusty, oily, and demanding environments
-> IP66 protection rating – reliable for indoor and outdoor use
-> Thermoelectric cooler

Technical data
Weight 5,2 kg
Mounting type

semi-recessed, wall mounted

Voltage

24V DC

Cooling capacity L35/L35

75W

Kind of protection

IP66

Mounting

Recessed

Dimensions

250x203x160mm

Housing material

Stainless steel AISI 304 (V2A)

Type of connection

6-pole connector plug

Operating temperature

-20°C bis +70°C

Storage temperature

-40°C bis +70°C

Approvals

CE, UKCA
