Thermoelectric coolers ST 6805
from 5.070,00 € excl. VAT
from 6.033,30 € incl. VAT
excl. VAT
ST Peltier cooling units offer a reliable, refrigerant-free solution for industrial cooling. They are based on the Peltier effect and are therefore particularly environmentally friendly and low-maintenance.
The units can be used in a wide variety of installation positions – either semi-recessed or wall-mounted – and can therefore be flexibly adapted to different types of control cabinets.
With a power range from 30 W to 800 W, the cooling units cover applications from small control boxes to large control cabinets. They also guarantee stable performance at temperatures from -20 °C to +70 °C and in dusty or oily environments. The high IP66 protection rating makes them suitable for both indoor and outdoor use.
Features:
-> Low-maintenance cooling without refrigerant
-> Integrated control
-> Flexible installation as a semi-mounted or Wall-mounted in any position
-> Robust design for dusty, oily, and demanding environments
-> IP66 protection rating – reliable for indoor and outdoor use
-> Thermoelectric cooler
| Weight | 66 kg |
|---|---|
| Mounting type | semi-recessed, wall mounted |
| Voltage | 230 V ∼ 50/60 Hz |
| Cooling capacity L35/L35 | 800W |
| Kind of protection | IP66 |
| Integrated control | Display of measured temperature via a display, Setting options: Cooling setpoint, high temperature setpoint, low temperature setpoint |
| Mounting | Recessed |
| Dimensions | 975x517x202mm |
| Housing material | Stainless steel AISI 304 (V2A) |
| Type of connection | 4-pole power connector; 5-pole connector for signals |
| Operating temperature | -20°C bis +70°C |
| Storage temperature | -40°C bis +70°C |
| Approvals | CE, UKCA, cURus |
