Thermoelectric coolers ST 6155
from 1.356,00 € excl. VAT
from 1.613,64 € incl. VAT
excl. VAT
The ST series Peltier cooling units offer compact, reliable cooling based on the Peltier effect – without the use of refrigerants. This technology enables efficient, low-maintenance operation and a long service life for the units.
The units can be mounted flexibly, either as an add-on or semi-built-in solution, and thus fit into a wide variety of control cabinets and housing types.
With a power range from 30 W to 800 W, they are suitable for many applications – from compact control boxes to extensive control cabinet solutions. They also provide constant cooling in dusty or oily environments and at temperatures from -20 °C to +70 °C. With protection class IP66, they are ideally suited for indoor and outdoor use.
Features:
-> Low-maintenance cooling without refrigerant
-> Integrated control
-> Flexible installation as a semi-mounted or Wall-mounted in any position
-> Robust design for dusty, oily, and demanding environments
-> IP66 protection rating – reliable for indoor and outdoor use
-> Thermoelectric cooler
| Weight | 18 kg |
|---|---|
| Mounting type | semi-recessed, wall mounted |
| Voltage | 230 V ∼ 50/60 Hz |
| Cooling capacity L35/L35 | 150W |
| Kind of protection | IP66 |
| Integrated control | Display of measured temperature via a display, Setting options: Cooling setpoint, high temperature setpoint, low temperature setpoint |
| Mounting | Recessed |
| Dimensions | 500x333x181mm |
| Housing material | Stainless steel AISI 304 (V2A) |
| Type of connection | 4-pole power connector; 5-pole connector for signals |
| Operating temperature | -20°C bis +70°C |
| Storage temperature | -40°C bis +70°C |
| Approvals | CE, UKCA, cURus |
